Visatron VN2020 Spare Parts

The system consists of following key parts:

1. Inspection cover
2. Inspection cover gasket
3. Measuring head
4. Lithium battery
5. Fuse
6. Connection casing
7. Connection casing gasket
8. Ejector in-/output system
9. Terminal box incl. measuring head cable
10. Base plate
11. Mea. head gasket
12. Flexible bellow
13. Pressure regulator
14. Filter element
15. Flexible scavenging hose system
16. Upper- & lower suspension

Spare part kits:

Assembly unit oil mist detector VN2020Part no.: 155000 (click for more info)
  • Complete oil mist detector VN2020
  • Pressure regulator
  • Protection cover
  • Quick guide
  • x1
  • x1
  • x1
  • x1
Measuring head VN2020Part no.: 290044 (click for more info)
  • Complete oil mist detector VN2020
  • Quick guide
  • x1
  • x1
Suspension & flexible bellow kitPart no.: 100163 (click for more info)
  • Upper suspension
  • Lower suspension
  • Flexible bellow
  • Mounting screws for fastening rings
  • Quick guide
  • x2
  • x2
  • x2
  • x4
  • x1
Terminal box kitPart no.: 100164
  • Complete terminal box with main cable and socket
  • Quick guide
  • x1
  • x1
Pressure regulator overviewPart no.: See below (click for more info)
  • Schaller pressure regulator
  • Schaller pressure regulator – Opposite flow direction
Pressure regulator filter kit x2Part no.: 155005/366717
  • Filter element kit
  • Quick guide
  • x2
  • x1
Maintenance Schaller kit for VN2020Part no.: 155004 (click for more info)
  • Inspection cover gasket
  • Measuring head gasket
  • Flexible bellows
  • Valve box gasket
  • Upper suspension
  • Lower suspension
  • Quick guide
  • x1
  • x1
  • x2
  • x1
  • x2
  • x2
  • x1
Lithium battery kit VN2020Part no.: 100172
  • Lithium battery
  • x1
Fuse kitPart no.: 100173
  • Fuse for measuring head system
  • x1

Maintenance Kits For VN2020

The kits consist of exact quantities of parts to be replaced during the maintenance work for this model. The kits do not contain Measuring head, Base plate, Connecting casing or Connection socket.

Test and cleaning of infra-red sensor kit | Part no: 100160

  •  Test kit needed every 6 months or every 4 000 operating hours.

Maintenance kit-2 | Part no: 100161

  • Maintenance kit-2 is needed every 6 months or every 4 000 operating hours.

Maintenance kit-3 | Part no: 100162

  • Maintenance kit-3 is needed every 24 months or every 16 000 operating hours, in this case maintenance kit-2 is not needed.

            NB! Must be performed by authorized service personnel!

Along with Visatron VN2020 came Schaller Automations new pressure regulator, effectively retiring the old one. If you now need a new pressure regulator, but you have the old model you will need to modify your system to be able to fit the 2020 regulator.
