Visatron VN115/93 Spare Parts

The system consists of following key parts:

Measuring head - 11201
Fresh air filter - 10042
Inspection cover gasket - 11180
Inspection cover - 10798
Plug R1/4" - 10083
Plug R1/4" gasket - 10082
Fresh air restrictor - 10992
Screw R1/2" - 10208
Screw R1/2" gasket - 10209
Connection casing - 11232
Mounting plate - 10991
Mea. head gasket - 10969
Flexible bellow - 10023
Fresh air bellow - 10990
Oil mist seal - 10206
Valve box gasket - 10405
Connection socket - 10905
Base plate - 10904

Part kits for VN 115/93:

100153-151489 – Yearly maintenance kit for VN 115/93

Kit to be used annually for maintenance.

Parts:

2 x Part no.: 10042 – Fresh air filter

2 x Part no.: 10992 – Fresh air restrictors

2 x Part no.: 10023 – Flexible bellow

1 x Part no.: 10969 – Measuring head gasket for VN/93

1 x Part no.: 11180 – Inspection cover gasket for VN/93

1 x Part no.: 10562 – Air-jet pump gasket

3 x Part no.: 10209 – Plug 1/2″ gasket

1 x Part no.: 10206 – Oil mist seal

1 x Part no.: 10990 – Fresh air bellow

1 x Part no.: 355095 – Air-jet pump gasket VN/93

1 x Part no.: 10405 – Connection casing gasket

1 x Part no.: 10003 – O-ring 9,0×4,5 NBR872

1 x Part no.: 10004 – O-ring 8,0×2,572 NBR872

1 x Part no.: 10679 – O-ring 4,0×1,75 NBR70

1 x Part no.: 155005 – Pressure regulator filter (new type)

1 x Part no.: 10002 – Pressure regulator filter (old type)

100153BU – Gasket kit for VN 115/93

Kit to be used during measuring head change. Replacing these parts are precautionary measure to avoid problems post-maintenance.

Parts:

1 x Part no.: 10969 – Measuring head gasket for VN/93

1 x Part no.: 11180 – Inspection cover gasket for VN/93

2 x Part no.: 10023 – Flexible bellow

1 x Part no.: 10206 – Oil mist seal

1 x Part no.: 10990 – Fresh air bellow

1 x Part no.: 10405 – Connection casing gasket

151490 – Maintenance kit for VN/93 series

Parts:

10 x Part no.: 10042 – Fresh air filter

4 x Part no.: 10992 – Fresh air restrictors

2 x Part no.: 11180 – Inspection cover gasket for VN/93

2 x Part no.: 155005 – Pressure regulator filter (new type)

3 x Part no.: 10002 – Pressure regulator filter (old type)

3 x Part no.: 10003 – O-ring 9,0×4,5 NBR872

Along with Visatron VN2020 came Schaller Automations new pressure regulator, effectively retiring the old one. If you now need a new pressure regulator, but you have the old model you will need to modify your system to be able to fit the 2020 regulator.
